Power:

24W

Input：

AC100-240V

Output Voltage:

5V DC

7.5V DC

9V DC

12V DC

15V DC

24V DC

Output Current:

0-4A

0-3A

0-2.5A

0-2A

0-1.6A

0-1A

Inrush Current:

65 Amps max. at 230VAC/50Hz,full load

Leakage Current:

＜100μA

No Load Power Consumption ：

＜0.5W

Protections：

Short Circuit /Over Current /Over Voltage/over temperature protection

Short Circuit Protection (SCP)：

Protection to Zero Voltage

Over Voltage Protection (OVP):

≤Vout*150%

Over Current Protection (OCP):

110%-180%

Withstand voltage:

I/P-O/P 4kVAC

Working TEMP.:

-20°C-50°C

EMC standards:

EN55011 class B,EN61000-3-2,3EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN60601-1-2 medical level,FCC Part 15 class B, EAC TP TC 020

Safety standards:

ANSI/AAMI ES60601-1/ES60601-1-11,CAN/CSA-C22,TUV EN60601-1-11,EAC TP TC 004 approved

Dimension:

105*45*28.5mm
