INPUT

Input Voltage:

85-264VAC

Input Frequency:

50/60Hz

Inrush Current:

35A/115VAC    70A/230VAC

AC Current:

0.33A/115VAC  0.21A/230VAC

Efficiency:

77%

81%

81%

84%

OUTPUT

DC Voltage:

5V

12V

15V

24V

Rated  Current :

2A

0.84A

0.67A

0.42A

Rated  Power:

10W

10W

10W

10W

Ripple and Noise:

80mVp-p

120mVp-p

120mVp-p

150mVp-p

Line Regulation:

±1%

Load Regulation:

±5%

±3%

±3%

±2%

Setup, Rise, Hold Up time:

500ms, 30ms/230VAC 1000ms, 30ms/115VAC at full load

ENVIRONMENTAL

Operating Temperature:

-20 ~ +60 (Refer to "Derating Curve")

Storage Temperature:

-40℃ ~ 85℃

Storage Humidity:

10 ~ 95% RH

Working Humidity:

20 ~ 95% RH non-condensing

PROTECTION

Over Load Protection:

105%-150% rated output power

Protection type: Hiccup mode, recovers automatically after fault
condition is removed

Over Voltage Protection:

5V:5.75~ 6.75V 12V:13.8 ~ 16.2V  15V:17.25 ~ 20.25V
24V:27.6 ~ 32.4V

Protection type : Shut down o/p voltage, re-power on to recover

Over Temperature:

Shut down o/p voltage, re-power on to recover

FUNCTION

DC OK ACTIVE
     SIGNAL(max.)

3.75 ~ 6V
      / 50mA

9 ~ 13.5V
      / 40mA

11.5 ~ 16.5V
      / 40mA

18 ~ 27V
     / 20mA

SAFETY &  EMC

Safety Regulations:

UL508, TUV BS EN/EN62368-1, EAC TP TC 004, BSMI CNS14336-1,
AS/NZS 62368.1 approved

Withstand Voltage:

I/P-O/P:3KVAC     I/P-FG:2KVAC     O/P-FG:0.5KVAC

Isolation resistance:

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

EMC emission:

Compliance to BS EN/EN55032 (CISPR32), BS EN/EN61204-3
Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020, CNS13438 Class B

OTHER

Size:

23*100*92mmm

Weight:

150g  / pcs

Packaging:

72PCS/CTN
